DZOFilm Pictor Bundle_14-30/50-125/20-55 T2.8 WHT

by DZOFilm
Raspoloživost: Isporuka 14-20 dana
SKU
DZO-7220001W/2W/3W-Kit

14 to 30mm Super35 Parfocal Zoom Lens, 20 to 55mm Super35 Parfocal Zoom Lens, 50 to 125mm Super35 Parfocal Zoom Lens, Lens Case with Foam Insert Included

73.100,00 kn 58.480,00 kn

Sadržaj pakiranja

  • DZOFilm Pictor 20 to 55mm T2.8 Super35 Parfocal Zoom Lens (PL Mount and EF Mount)
  • Front Lens Cap
  • Rear Lens Cap
  • Zoom Stick
  • Canon EF-Mount with Cap
  • DZOFilm Pictor 50 to 125mm T2.8 Super35 Parfocal Zoom Lens (PL Mount and EF Mount)
  • Front Lens Cap
  • Rear Lens Cap
  • Zoom Stick
  • Canon EF-Mount with Cap
  • DZOFilm Pictor 14-30mm T2.8 Super35 Parfocal Zoom Lens (PL and EF Mounts, Black)
  • Front Lens Cap
  • PL Rear Lens Cap
  • Shim Set
  • Support Rod
  • Canon EF-Mount Bayonet
  • EF Rear Lens Cap
  • DZOFilm Empty Hard Case for Pictor Zoom Lenses (3-Lens)
  • Interior Foam

This Pictor T2.8 Super35 Zoom 3-Lens Bundle from DZOFilm consists of three zoom lenses—the 14 to 30mm, 20 to 55mm, and 50 to 125mm—with a standard black finish. The lenses provide coverage of an extended zoom range with a relatively fast maximum aperture. Both cover Super35 sensors and have similar lengths, weight, lens gear positions, and front outer diameter, making for fast lens swaps.

Each lens comes standard with a PL mount and includes a Canon EF Mount for compatibility with a wide range of digital cinema cameras. The lenses hold focus throughout the focal length range and feature matching 16-blade irises for producing round out-of-focus highlights. This bundle includes a durable protective case for transport and storage.

Note:
Please Note: According to the manufacturer, when converted to EF mount this lens is not compatible with DSLR cameras that have an EF mount. However, it is compatible with mirrorless cameras that have an EF mount, including Blackmagic Design cameras.

DZOFilm Pictor 20 to 55mm T2.8 Super35 Parfocal Zoom Lens (PL Mount and EF Mount)

A parfocal cine lens, the DZO Pictor 20 to 55mm T2.8 Super35 Parfocal Zoom Lens features a relatively fast maximum aperture of T2.8 with an aperture range of T2.8 to T22. As you would expect from a cinema-style zoom, the lens is parfocal, meaning it holds focus throughout the zoom range. The internal focus design with floating elements virtually eliminates focus breathing. It covers a Super35 image circle, comes standard with an interchangeable PL mount, and includes an EF mount.

The 16-blade iris creates round out-of-focus highlights, which have a more natural appearance and contribute to the lens's natural-looking bokeh. The lens features cine-style gear rings on the focus, iris, and zoom lens rings, making it compatible with cine-style lens accessories such as follow focus units, lens motors, and lens control systems. The 95mm outer front diameter allows you to use a variety of compatible third-party matte boxes, and the lens has an 86mm filter thread. A lens support foot allows you to support the lens on rods to help reduce strain on your camera's lens port.

Note:
Please Note: According to the manufacturer, when converted to EF mount this lens is not compatible with DSLR cameras that have an EF mount. However, it is compatible with mirrorless cameras that have an EF mount, including Blackmagic Design cameras.

Key Features

  • Maintains focus throughout the zoom range
  • Minimal breathing
  • 16-blade iris produces round out-of-focus highlights
  • T2.8 to T22 aperture
  • 95mm front diameter
  • Compatible with standard cine-style lens accessories

DZOFilm Pictor 50 to 125mm T2.8 Super35 Parfocal Zoom Lens (PL Mount and EF Mount)

A parfocal cine lens, the DZO Pictor 50 to 125mm T2.8 Super35 Parfocal Zoom Lens features a relatively fast maximum aperture of T2.8 with an aperture range of T2.8 to T22. As you would expect from a cinema-style zoom, the lens is parfocal, meaning it holds focus throughout the zoom range. The internal focus design with floating elements virtually eliminates focus breathing. It covers a Super35 image circle, comes standard with an interchangeable PL mount, and includes an EF mount.

The 16-blade iris creates round out-of-focus highlights, which have a more natural appearance and contribute to the lens's natural-looking bokeh. The lens features cine-style gear rings on the focus, iris, and zoom lens rings, making it compatible with cine-style lens accessories such as follow focus units, lens motors, and lens control systems. The 95mm outer front diameter allows you to use a variety of compatible third-party matte boxes, and the lens has an 86mm filter thread. A lens support foot allows you to support the lens on rods to help reduce strain on your camera's lens port.

Note:
Please Note: According to the manufacturer, when converted to EF mount this lens is not compatible with DSLR cameras that have an EF mount. However, it is compatible with mirrorless cameras that have an EF mount, including Blackmagic Design cameras.

Key Features

  • Maintains focus throughout the zoom range
  • Minimal breathing
  • 16-blade iris produces round out-of-focus highlights
  • T2.8 to T22 aperture
  • 95mm front diameter
  • Compatible with standard cine-style lens accessories

DZOFilm Pictor 14-30mm T2.8 Super35 Parfocal Zoom Lens (PL and EF Mounts, White)

The black Pictor 14-30mm T2.8 Super35 Parfocal Zoom Lens from DZOFilm features a relatively fast maximum aperture of T2.8 with an aperture range of T2.8 to T22, and it adds an extreme wide-angle zoom to the Pictor line of lenses. As you would expect from a cinema-style zoom, the lens is parfocal, meaning it holds focus throughout the zoom range. The internal focus design with floating elements virtually eliminates focus breathing. It covers a Super35 image circle, comes standard with an interchangeable PL mount, and includes an EF mount.

The 16-blade iris creates round out-of-focus highlights, which have a more natural appearance and contribute to the lens's natural-looking bokeh. The lens features cine-style gear rings on the focus, iris, and zoom lens rings, making it compatible with cine-style lens accessories such as follow focus units, lens motors, and lens control systems. The 95mm outer front diameter allows you to use a variety of compatible third-party matte boxes, and the lens has an 86mm filter thread. A lens support foot allows you to support the lens on rods to help reduce strain on your camera's lens port.

Note:
Please Note: According to the manufacturer, when converted to EF mount this lens is not compatible with DSLR cameras that have an EF mount. However, it is compatible with mirrorless cameras that have an EF mount, including Blackmagic Design cameras.

Key Features

  • Maintains focus throughout the zoom range
  • Minimal focus breathing
  • 16-blade iris produces round out-of-focus highlights
  • T2.8 to T22 aperture
  • Common Pictor 95mm front diameter
  • Compatible with standard cine-style lens accessories

DZOFilm Empty Hard Case for Pictor Zoom Lenses (3-Lens)

The Empty Hard Case from DZOFilm is a hard-shell case that fits the three 14-30mm, 20-55mm, and 50-125mm Pictor zooms, plus several lens accessories. This case interior features a laser-cut foam insert that cradles and protects each lens. There are separate slots for accessories, shim sets, and lens mounts.

Equipment Accommodated

  • DZOfilm Pictor 14-30mm T2.8 zoom lens
  • DZOfilm Pictor 20-55mm T2.8 zoom lens
  • DZOfilm Pictor 50-125mm T2.8 zoom lens
  • Lens accessories
  • Custom Foam
  • Laser-cut foam interior cradles each zoom

DZOFilm Pictor 20 To 55mm T2.8 Super35 Parfocal Zoom Lens (PL Mount And EF Mount) Specs

Focal Length 20 to 55mm
Lens Mount ARRI PL
Lens Format Coverage Super35/APS-C
Image Circle 31.1 mm
Maximum Aperture T2.8
Minimum Aperture T22
Diaphragm Blades 16
Gear MOD & Pitch Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Zoom: 0.8 MOD / 32 Pitch
Front Diameter 95 mm
Filter Thread 86 mm
Focus Scales Imperial
Zoom Ratio 2.75x
Electronic Communication No
Image Stabilization No
Lens Support Lens Support Foot
Length 6.46" / 164 mm
Weight 3.35 lb / 1.52 kg

DZOFilm Pictor 50 To 125mm T2.8 Super35 Parfocal Zoom Lens (PL Mount And EF Mount) Specs

Focal Length 50 to 125mm
Lens Mount ARRI PL
Lens Format Coverage Super35/APS-C
Image Circle 31.1 mm
Maximum Aperture T2.8
Minimum Aperture T22
Diaphragm Blades 16
Gear MOD & Pitch Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Zoom: 0.8 MOD / 32 Pitch
Front Diameter 95 mm
Filter Thread 86 mm
Focus Scales Imperial
Zoom Ratio 2.5x
Electronic Communication No
Image Stabilization No
Lens Support Lens Support Foot
Length 6.89" / 175 mm
Weight 3.75 lb / 1.7 kg

DZOFilm Pictor 14-30mm T2.8 Super35 Parfocal Zoom Lens (PL And EF Mounts, White) Specs

Focal Length 14 to 30mm
Lens Mount ARRI PL
Lens Format Coverage Super35/APS-C
Image Circle 31.1 mm
Maximum Aperture T2.8
Minimum Aperture T22
Minimum Focus Distance From Unspecified Point in Lens: 2.0' / 0.6 m
Optical Design 21 Elements in 17 Groups
Diaphragm Blades 16
Gear MOD & Pitch Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Zoom: 0.8 MOD / 32 Pitch
Front Diameter 95 mm
Filter Thread 86 mm
Focus Scales Imperial
Focus Rotation 270°
Iris Rotation 61°
Zoom Rotation 100°
Zoom Ratio 2.14x
Electronic Communication No
Image Stabilization No
Lens Support Lens Support Foot
Length 6.8" / 173 mm
Weight 4.1 lb / 1880 g

DZOFilm Empty Hard Case For Pictor Zoom Lenses (3-Lens) Specs

Carry/Transport Options Handle
Color Black
Type of Closure Latch
Laptop/Tablet Compartment None
Interior Type Insert with Custom Compartments

Environmental

Water Resistance Waterproof
