Seetec P215-9HSD SDI monitor

by Seetec
Dostupnost: Isporuka 14-20 dana
SKU
P215-9HSD
  • Full HD Display, Supports up to 1080p60
  • 178 / 178° Viewing Angle
  • HDMI, 3G-SDI & Analog Inputs/Outputs
826,25 € 661,00 €

Sadržaj pakiranja

  • FeelWorld 21.5'' Full HD IPS Broadcast Monitor
  • Mini HDMI Cable
  • V-Mount Battery Plate (Pre-Installed)
  • 3A Power Adapter
  • Tally Kit
  • Stand Bracket

The 21.5" Full HD IPS Broadcast Monitor from FeelWorld features a 1920 x 1080 display and supports up to 1080p60 signals. It comes with a robust stand bracket that lets you set it down on flat surfaces and adjust the tilt angle. For carrying the monitor around, there's a hand slot on the rear that lets you easily grab it and carry it from place to place on location.

The monitor offers HDMI, 3G-SDI, and analog inputs and outputs, RCA audio inputs, and a tally port. All of these are on the rear, next to an integrated V-mount battery plate and 4-pin XLR and barrel power inputs. A headphone jack and built-in speakers are available for audio monitoring, and a 3-color LED tally light is provided on the top of the front panel.

Image analysis functions include peaking focus assist, zoom, and pixel-to-pixel, and these are assignable across six function buttons on the front panel.

Key Features

  • 1920 x 1080 resolution IPS display
  • Supports up to 1080p60 signals
  • HDMI, 3G-SDI, component BNC, composite BNC, and RCA audio inputs
  • HDMI, 3G-SDI, component BNC, composite BNC outputs
  • 178 / 178° viewing angle
  • Color depth: 16.7M colors
  • Tally port
  • Built-in red/green/yellow LED tally indicators
  • 3.5mm stereo headphone jack
  • Built-in speakers
  • Integrated V-mount plate
  • 250 cd/m² brightness
  • 3000:1 contrast ratio
  • 4-pin XLR and DC barrel power ports
  • Hand slot on the monitor's rear panel for alternative carry options

Image Analysis Functions

  • Peaking focus assist
  • Check field
  • Camera mode
  • Pixel-to-pixel
  • Center marker
  • Safe marker (80, 85, 90, 93, 96, 2.35:1)
  • Image flip (horizontal, vertical, horizontal and vertical)
  • Image freeze
  • Zoom all
  • U/D and L/R zoom

FeelWorld P 9HSD Monitor Specs

Display

Panel Type

IPS-Type LCD

Display Size

21.5" / 54.6 cm

Resolution

1920 x 1080

Aspect Ratio

16:9

Viewing Angle

Horizontal: 178°
Vertical: 178°

Touchscreen

No

Maximum Brightness

250 cd/m2

Contrast Ratio

3000:1

I/O

Video

1 x HDMI Type A Input
1 x BNC (3G-SDI) Input
1 x 3BNC (Component) Input
1 x BNC (Composite) Input
1 x HDMI Type A Output
1 x BNC (3G-SDI) Output
1 x 3BNC (Component) Output
1 x BNC (Composite) Output

Embedded Audio

HDMI
SDI

Audio

1 x 2RCA Input
1 x 1/8" / 3.5 mm Headphone Output

Built-In Speaker

2

Power I/O

1 x XLR 4-Pin Input
1 x Barrel Input

Other I/O

1 x Tally (DE-9/DB-9)

Media/Memory Card Slot

None

Format Support

Video Format

HDMI
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
1080PsF: 24/23.98
720p: 60/59.94/50/30/29.97/25/24/23.98
576p
480p
576i
480i
SDI
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
1080PsF: 24/23.98
720p: 60/59.94/50/30/29.97/25/24/23.98
576i
480i

Power

Battery Type

1 x V-Mount

Power Consumption

15 W (Maximum)

Environmental

Operating Temperature

14 to 122°F / -10 to 50°C

Storage Temperature

-4 to 140°F / -20 to 60°C

General

Dimensions

20.1 x 14 x 1.5" / 51 x 35.5 x 3.8 cm
21.1 x 15.7 x 3.9" / 53.5 x 40 x 10 cm, Including Bracket

Weight

13.49 lb / 6.12 kg, Including Bracket

Packaging Info

Package Weight

17.185 lb

Box Dimensions (LxWxH)

24.3 x 19.5 x 4.8"
