SOMMER CABLE video cable SC-RG Classic Broadcast

by Sommer Cable
Raspoloživost: Isporuka 7-10 dana
SKU
600-0144

Video cable SC-RG Classic Broadcast; 1 x 1,00; PVC Ø 7,10 mm; green.

2,32€/17,50 kn 1,86€/14,00 kn
Tečaj konverzije: 1 EUR = 7,53450 HRK

Suited for short and long distance flights

this is SC-RG Classic Broadcast 1.0/4.8. It meets all the requirements put today on high-quality HD-SDI/HDTV cables and the use of high-class materials promises a long service life. To achieve ultralow damping values we have equipped the cable with a solid core wire of oxygen-free copper (OFC), a gas-injected insulation and a dual screen (Cu mesh + AL/PT foil). Please note the transmission distances for HD-SDI transfer stated in the technical data (see chart). Of course, with analogue video transmissions far greater transmission distances will be possible.

Advantages:

  • Long life due to non-aging jacket
  • Consistent, optimised electrical values due to the use of a massive
    OFC wire
  • Gas-injected insulation for best damping values

Application:

  • HD-SDI-video transmission in the professional broadcasting/studio sector
  • OB van technology
  • HF technology and antenna construction
  • For fixed installations
Name SC-RG Classic Broadcast
Properties OFC oxygen free copper
Properties HDTV
Properties SDI
Properties Analog
Properties Digital 75 Ω
Application area Installation
Application area ELA 100 V
Application video cable
Colour green
Colour detailed green
Construction 02YS(ST)CH1,0/4,8 HD-SDI
Jacket material PVC
Jacket Ø [mm] 7,10
Number of Channels (video) 1
Inner conductor (video) 1
Inner conductor (video) [mm²] 0,79
Inner conductor Ø (video) [mm] 1,00
AWG (video) 18
Shielding Copper braiding tin-plated + AL / PT foil
Copper strands (video) 1
Copper strand Ø (video) [mm] 1,00
Conductor insulation material Gas Injected-PE
Conductor insulation Ø [mm] 4,80
Weight per 1 m [g] 64
Fire load per m [kWh] 0,21
Style variant round
Shielding factor [%] 100
Packing 1000 m spool
Packing 100 m spool
Packing 500 m spool
Velocity factor 0,82
Temperature min. [°C] -30
Temperature max. [°C] 70
Max. transmission distance (HD-SDI) [m] 150
Max. transmission distance (3G) [m] 100
Width [mm] 7,1
Height [mm] 7,1
Capacity wire/electic screen at 1m (video) [pF] 53
Capacity wire/electic screen at 1 ft. (video) [pF] 16,1544
Damping at 50 MHz (100m & 20° C) [dB] 4,5
Damping at 50 MHz (100 ft. & 20 °C / 68 °F) [dB] 1,3716
Damping at 200 MHz (100m & 20° C) [dB] 8,9
Damping at 200 MHz (100 ft. & 20 °C / 68 °F) [dB] 2,7127
Damping at 470 MHz (100m & 20° C) [dB] 13,9
Damping at 470 MHz (100 ft. & 20 °C / 68 °F) [dB] 4,2367
Damping at 862 MHz (100m & 20° C) [dB] 18,9
Damping at 862 MHz (100 ft. & 20 °C / 68 °F) [dB] 5,7607
Damping at 1000 MHz (100m & 20° C) [dB] 20,3
Damping at 1000 MHz (100 ft. & 20 °C / 68 °F) [dB] 6,1874
Damping at 1485 MHz (100m & 20° C) [dB] 24,7
Damping at 1485 MHz (100 ft. & 20 °C / 68 °F) [dB] 7,5286
Damping at 1750 MHz (100m & 20° C) [dB] 28,8
Damping at 1750 MHz (100 ft. & 20 °C / 68 °F) [dB] 8,7782
Damping at 2150 MHz (100m & 20° C) [dB] 30,3
Damping at 2150 MHz (100 ft. & 20 °C / 68 °F) [dB] 9,2354
Damping at 3000 MHz (100m & 20° C) [dB] 38,5
Damping at 3000 MHz (100 ft. & 20 °C / 68 °F) [dB] 11,7348
Impedance [Ω] 75
Shield. resistance per 1 km [Ω] 7
Shield. resistance per 1000 ft. [Ω] 2,1336
EAN 4049371001809
