Sony PXW-FS7 Camcorder
by Sony
Dostupnost:
Isporuka 7-10 dana
SKU
S-PXWFS7
PXW-FS5 XDCAM Super 35 Camera System captures UHD video using a Super 35mm-sized sensor for cinematic imagery.
8.262,00 €
6.609,60 €
- Plaćanje na rate Plaćajte na rate Visa, Visa Premium, Maestro, MasterCard i Diners kreditnim karticama. Naknada je 5% na objavljenu cijenu a zaračunava se u košarici prilikom odabira plaćanja. Više detalja provjerite na linku Načini plaćanja.
- Brza dostava Za sve narudžbe unutar RH zaprimljene do 14h dostava će biti izvršena sljedećeg radnog dana*. Za cijelu Europu vršimo brzu dostavu, a više detalja provjerite na linku Načini dostave.
- Međunarodna kupnja EU tvrtke(osim RH) s valjanim VAT ID brojem plaćaju cijenu bez PDV-a. Cijena će se obračunati prilikom check out-a. Svi kupci izvan EU plaćaju izvoznu cijenu bez PDV-a.
Sadržaj pakiranja
- Sony PXW-FS7 XDCAM Super 35 Camera System
- Body Cap
- Viewfinder
- Eyepiece
- Grip Remote Control
- Wireless LAN USB Module (IFU-WLM3) for Sony VPL-E200 Series Projectors
- Wireless Remote Commander (RMT-845)
- WA Adaptor Bracket
- MPA-AC1 AC Adapter for EVI D100 CCD Camera
- BC-U1 Battery Charger
- BP-U30 Lithium-Ion Battery
- 2 x Power Cord
- USB Cable
- CD Rom with Manuals
Designed as a camera that is at home on productions as diverse as "Cinéma Vérité"-style documentaries, reality TV, commercial and corporate applications Sony's PXW-FS7 XDCAM Super 35 Camera System is a flexible 4K camera system. It features a Super 35mm size sensor that allows you to capture images with cinematic depth of field. The camera's E-mount is machined from stainless steel and allows you to use E-mount lenses or with the use of optional adapters to accept most 35mm lenses including PL, EF, Leica, and Nikon. The camera can capture footage to optional on-board XQD media cards in either DCI (4096 x 2160), UHD (3840 x 2160) at up to 60 FPS or HD at up to 180 FPS.
The camera records in your choice of XAVC-I, XAVC-L, or MPEG-2. However, MPEG-2 recording does not support the high data rates the camera is capable of generating when shooting in UHD, and is limited to recording HD video only. The camera incorporates Dual XQD media card slots that support simultaneous or relay recording. An ergonomically designed handgrip provides control of many of the camera's functions and features an adjustable length support arm.
- XQD-G-E Card Firmware
- To use the the faster XQD-G-E cards requires an update to firmware 4.00 available from the Sony website.
- Firmware 2.0
- The Firmware 2.0 update is installed on the camera, it is a free download and user install for camera owners who do not already have it installed in their camera. The firmware 2.0 update adds the following features to your camera:
- 1.Expands audio recording to four channels audio at 24-bit, 48 KHz.
- 2.Supports DCI compliant 4096 x 2160 XAVC-Intra-frame recording up to 60 fps.
- 3.Adds HD Apple ProRes codecs to enable progressive and interlaced HQ and 422 recording.
- 4.Eliminates "Magenta Cast" in WB preset mode.
- 5.Renames "Color Temp" menu parameter to "Preset White"
- 6.Eliminates need to re-enable "Steady Shot" after power ON/OFF cycle.
- 7.Retains "Paint Menu" settings after power OFF/ON cycle.
- The 4K Super35 EXMOR sensor features 14 Stops of latitude and a wide color gamut. It offers a choice of XAVC or MPEG-2 codecs. The XAVC codec can be used for 4K and HD recording, while MPEG-2 is limited to HD recording. XAVC comes in two flavors, XAVC INTRA, and XAVC Long, allowing you to encode from HD to UHD using Intra-Frame or Long GoP compression with 10-bit 422 for HD and the choice of 10-bit 422 or 8-bit 420 for UHD. XAVC intra compression is very efficient, recording at modest bit rates and XAVC Long also substantially extends the recording time while attaining very high quality and low noise.
- The PXW-FS7 is equipped with an E-Mount machined from solid Stainless Steel for stability and strength. It accepts optional E-Mount lenses from Sony, Zeiss and other manufacturers. The shallow flange distance allows you to mount most 35mm lens types such as PL, DSLR and legacy SLR lenses including Canon EF, Leica, and Nikon as well as many others with mechanical adapters.
- The camera body is made from magnesium, which is lighter and stronger than aluminum. This allows the camera body to weigh only four pounds. It's incorporates a shoulder pad and is designed to sit on the operator's shoulder or by extending the support arm of the SmartGrip to be held in front of the operator without requiring a support rig.
- The camera includes an ergonomic handgrip that Sony calls a SmartGrip, which features Zoom, Start/Stop and Assign controls. The SmartGrip facilitates camera operation with the right hand, leaving the left hand free to operate the lens. Both the arm and handgrip can be positioned at different angles permitting great flexibility.
- FS7 records internally in 4K up to 60fps in UHD 3840x2160 and in HD up to 180fps using XAVC-I or up to 120fps with XAVC-L. Recording Apple ProRes to the internal XQD slots requires an optional EXCA-FS7 extension box and future upgrade.
- 4K (4096 x 2160) is available when using an optional external recorder.
- The camera features two XQD media slots that support simultaneous or relay recording. The camera also has an SD card slot that is only used for saving configuration data, and cannot be used to record video.
| Image Device | Super 35mm Single-Chip Exmor CMOS |
| Effective Picture Elements | 17:9 4096 (H) x 2160 (V) 16:9 3840 (H) x 2160 (V) |
| Signal-to-Noise Ratio | 57 dB (Y) |
| Sensitivity | 2000 lx, 89.9% reflectance T14 (3840 x 2160/23.98p mode 3200K) ISO Sensitivity ISO 2000 (S-Log3 Gamma D55 Light source) |
| Minimum Illumination | 0.7 lux: +18dB,23.98P,Shutter OFF,ND Clear, F1.4 |
| Signal System | NTSC / PAL |
| Built-in Filters | Clear, 1/4, 1/16, 1/64 |
| LCD Monitor | 3.5" / 8.8 cm Approx: 1.56M dots |
| Speaker | Monaural |
| Shutter Speed | 1/3 to 1/9000 of a sec |
| White Balance | Preset Memory A Memory B (1500K-50000K)/ATW |
| Gain Selection | -3, 0, 3, 6, 9, 12, 18 dB, AGC |
| Gamma Curve | STD HG User S-log3 |
| Shooting Formats | 4K 4096 x 2160 12-bit RAW UHD 3840 x 2160 10-bit 4:2:2 XAVC-I 8-bit 4:2:0 XAVC-L 2K 2048 x 1080 12-bit Raw HD 1920 x 1080 10-bit 4:2:2 XAVC-I 10-bit 4:2:2 XAVC-L MPEG2 4:2:2 HD 1280 x 720 MPEG2 4:2:2 |
| Audio Recording Format | LPCM 24 bits, 48 kHz, 4 channels (Recording/Playback 2 channels) |
| Recording Formats | XAVC-I QFHD MPEG-4 H.264/AVC 59.94P CBG, bit rate 600 Mb/s 50P CBG, bit rate 500 Mb/s 29.97P CBG, bit rate 300 Mb/s 23.98P CBG, bit rate 240 Mb/s 25P CBG, bit rate 250 Mb/s XAVC-I HD MPEG-4 H.264/AVC 59.94P VBR, maximum bit rate 222 Mb/s 50P VBR, maximum bit rate 185 Mb/s 59.94i VBR, maximum bit rate 111 Mb/s 50i VBR, maximum bit rate 112 Mb/s 29.97p VBR, maximum bit rate 111 Mb/s 23.98p VBR, maximum bit rate 89 Mb/s 25p VBR, maximum bit rate 112 Mb/s XAVC-L QFHD MPEG-4 H.264/AVC 59.94p/50p mode: VBR, maximum bit rate 150 Mb/s 29.97p/23.98p/25p mode: VBR, maximum bit rate 100 Mb/s XAVC-L HD 50 MPEG-4 H.264/AVC VBR, maximum bit rate 50 Mb/s XAVC-L HD 35 MPEG-4 H.264/AVC VBR, maximum bit rate 35 Mb/s XAVC-L HD 25 MPEG-4 H.264/AVC VBR, maximum bit rate 25 Mb/s MPEG-2 Long GOP CBR, maximum bit rate 50 Mbps, MPEG-2 422P@HL XAVC-I QFHD 3840 x 2160/ 59.94p, 50p, 29.97p, 23.98p, 25p XAVC-I HD 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p XAVC-L QFHD 50 3840 x 2160/59.94p, 50p, 29.97p, 23.98p, 25p XAVC-L 35 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p MPEG-2 Long GOP 1920 x 1080/59.94i, 50i, 29.97p, 23.98p, 25p 1280 x 720/59.94p, 50p, 29.97p, 23.98p, 25p |
| Recording Frame Rate | XAVC-I QFHD 3840 x 2160/ 59.94p, 50p, 29.97p, 23.98p, 25p XAVC-I HD 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p XAVC-L QFHD 3840 x 2160/59.94p, 50p, 29.97p, 23.98p, 25p XAVC-L HD 50 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p XAVC-L 35 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p XAVC-L 25 1920 x 1080/59.94i, 50i MPEG-2 Long GOP MPEG HD422 1920 x 1080/59.94i, 50i, 29.97p, 23.98p, 25p 1280 x 720/59.94p, 50p, 29.97p, 23.98p, 25p |
| Slow & Quick Motion Function | XAVC-I mode 3840 x 2160: 1 to 60 frames (59.94p, 50p, 29.97p, 23.98p, 25p) XAVC-I mode 1920 x 1080: 1 to 180 frames (59.94p, 29.97p, 23.98p) XAVC-I mode 1920 x 1080: 1 to 150 frames (50p, 25p) XAVC-L mode 3840 x 2160: 1 to 60 frames (59.94p, 50p, 29.97p, 23.98p, 25p) XAVC-L mode 1920 x 1080: 1 to 120 frames (59.94p, 50p, 29.97p, 23.98p, 25p) |
| Maximum Recording Time | XAVC-I mode QFHD 59.94p When using QD-G128A (128 GB): Approx. 22 minutes When using QD-G64A (64 GB) Approx. 11 minutes XAVC-I mode QFHD 50p When using QD-G128A (128 GB): Approx. 26 minutes When using QD-G64A (64 GB) Approx. 13 minutes XAVC-I mode QFHD 29.97p When using QD-G128A (128 GB): Approx. 44 minutes When using QD-G64A (64 GB) Approx. 22 minutes XAVC-I mode QFHD 23.98p When using QD-G128A (128 GB): Approx. 55 minutes When using QD-G64A (64 GB) Approx. 27 minutes XAVC-I mode QFHD 25p When using QD-G128A (128 GB): Approx. 52 minutes When using QD-G64A (64 GB) Approx. 26 minutes XAVC-I mode HD 59.94p When using QD-G128A (128 GB): Approx. 59 minutes When using QD-G64A (64 GB) Approx. 30 minutes XAVC-I mode HD 50p When using QD-G128A (128 GB): Approx. 71 minutes When using QD-G64A (64 GB) Approx. 35 minutes XAVC-I mode HD 59.94i When using QD-G128A (128 GB): Approx. 118 minutes When using QD-G64A (64 GB) Approx. 59 minutes XAVC-I mode HD 50i When using QD-G128A (128 GB): Approx. 141 minutes When using QD-G64A (64 GB) Approx. 70 minutes XAVC-I mode HD 29.97p When using QD-G128A (128 GB): Approx. 118 minutes When using QD-G64A (64 GB) Approx. 59 minutes XAVC-I mode HD 23.98pM/b> When using QD-G128A (128 GB): Approx. 147 minutes When using QD-G64A (64 GB) Approx. 74 minutes XAVC-I mode HD 25p When using QD-G128A (128 GB): Approx. 141 minutes When using QD-G64A (64 GB) Approx. 70 minutes XAVC-L mode QFHD 59.94p/50p When using QD-G128A (128 GB): Approx. 87 minutes When using QD-G64A (64 GB) Approx. 44 minutes XAVC-L mode QFHD 29.97p/23.98p/25p When using QD-G128A (128 GB): Approx. 131 minutes When using QD-G64A (64 GB) Approx. 66 minutes XAVC-L 50 mode When using QD-G128A (128 GB): Approx. 262 minutes When using QD-G64A (64 GB) Approx. 131 minutes XAVC-L 35 mode When using QD-G128A (128 GB): Approx. 374 minutes When using QD-G64A (64 GB) Approx. 187 minutes XAVC-L 25 mode When using QD-G128A (128 GB): Approx. 524 minutes When using QD-G64A (64 GB) Approx. 262 minutes MPEG HD422 mode When using QD-G128A (128 GB): Approx. 262 minutes When using QD-G64A (64 GB) Approx. 131 minutes |
| Media Card Slots | 2 x XQD 1 x SD (for configuration data only) |
| Input and Output Connectors | Audio Input 2 x 3-pin XLR Line/mic/mic +48 Mic Reference: -40. -50. -60 dBu SDI Output 2 x BNC HD/3G-SDI SMTPE292M/424M/425M HDMI 2.0 1 x Type A USB USB device, miniB Headphone 1 x Stereo mini jack -16 dBu 16 Ω Remote Stereo mini jack (Φ2.5 mm) |
| Accessory Shoe | Multi-Interface (MI) shoe |
| Power Requirement | 12 VDC |
| Power Consumption | Approx. 19 W (while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device) |
| Battery Operating Time | BP-U30: Approx. 1 hr while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device BP-U60: Approx. 2 hr while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device BP-U90: Approx. 3 hr while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device |
| Temperature | Operating: 32 to 104°F / 0 to 40°C Storage: -4 to 140°F / -4 to 140°C |
| Dimensions (WxHxD) | 6.14 x 9.41 x 9.72" / 156 x 239 x 247 mm |
| Weight | 4.4 lb / 2.0 kg: Body Only 9.9 lb / 4.4 kg: Body, Viewfinder, Eyepiece, Grip Remote Control, BP-U30 Battery, SELP28135G Lens, an XQD Memory card |
