Tascam DR-07XP

by Tascam
Dostupnost: Dostupno
SKU
TASCDR-07XP

The DR-07XP portable handheld recorder makes it easy to capture pro-quality recordings for music, audio-for-video, meetings, dictation and more.

195,00 € 156,00 €

Sadržaj pakiranja

  • Tascam DR-07XP × 1
  • Safety Guide × 1
  • TASCAM ID registration guide × 1

Create Professional Audio Recordings From the Palm of Your Hand

The DR-07XP portable handheld recorder makes it easy to capture pro-quality recordings for music, audio-for-video, meetings, dictation and more. With 32-bit float recording mode, you’ll never need to worry about setting audio levels, and adjustable stereo condenser microphones give you full control over your sound.

With easy one-handed operation, the DR-07XP makes it simple to start recording with minimal setup time.

Capture Pro-Level Recordings Every Time

With its 32-bit float recording mode, the DR-07XP ensures your audio recordings will always be clear, distinct and free of distortion that could ruin your recording – and you’ll never need to worry about setting input levels.

Recording formats include 32-bit float, 24-bit and 16-bit at 96 kHz, 48 kHz, 44.1 kHz as well as MP3.

Adjustable Stereo Condenser Microphones

The DR-07XP features stereo condenser microphones with adjustable A-B or X-Y configurations, allowing you to capture incredibly vivid stereo recordings in any setting.

Simplicity in Your Palm

With the DR-07XP, the complexities of audio recording are a thing of the past. Easily access every feature from the palm of your hand.

Plus, the backlit LCD screen means no squinting, just clear and concise navigation any time of day, in any environment.

Your Portable Recording Studio

The DR-07XP isn’t only a powerful portable recorder — it’s also a 2-in/2-out USB-C audio interface you can use to record anywhere, directly to audio recording software on your Mac or PC.

Ideal for Musicians

The DR-07XP is a fantastic portable recording solution for musicians with its high-quality microphones, 32-bit float recording, built-in tuner, reverb, overdubbing and more.

On location

With its compact size, the DR-07XP can travel anywhere for exceptional field recording. Choose from four different low cut filter options for getting rid of unwanted noises.

As a companion for video, the DR-07XP can attach easily to tripods and the Auto Tone output for cameras makes post-production a simple task.

Record Anything, Anywhere

From dialogue to vlogs, whether you’re in an alley or a recording booth, the DR-07XP captures clear, crisp audio with ease. In addition to the built-in mics, use the stereo mini-jack to add microphones with plug-in power or external line inputs to capture audio from any source in mono or stereo.

Connect the unit to a computer via USB-C for use as a USB microphone.

General
Recording media microSD/microSDHC/microSDXC card (up to 512 GB)
Recording/playback format
WAV Sampling frequency: 44.1/48/96 kHz
  Quantization bit depth: 16-bit / 24-bit / 32-bit float
MP3 Sampling frequency: 44.1/48 kHz
  Bit rate: 32/64/96/128/192/256/320 kbit/s
Number of channels Input channels: 2 (stereo)
  Recording tracks: 2 (stereo)
Analogue audio inputs and outputs
Microphone/External input (can provide plug-in power) 3.5-mm stereo mini jack
Input impedance ≥18 kΩ (plug-in power off)
  ≥2 kΩ (plug-in power on)
Nominal input level −20 dBV
Maximum input level −4 dBV
Headpones/Line output 3.5-mm stereo mini jack
Output impedance 12 Ω
Nominal output level −14 dBV (10 kΩ load)
Maximum output level +2 dBV (10 kΩ load)
Maximum output power 20 mW + 20 mW (32 Ω load)
Working impedance 16−250 Ω
Built-in loudspeaker 0.3 W (mono)
Control inputs and outputs
USB Type-C connector
Format USB 2.0 HIGH SPEED mass storage class
  USB 1.1 FULL SPEED audio class
USB Audio
Sampling frequency 44.1/48 kHz
Quantization bit depth 24 bit
Number of audio inputs 2 channels
Number of audio outputs 2 channels
Audio performance
Frequency response 20 Hz – 20 kHz, +0/−1 dB
  (MIC/EXT IN to LINE OUT, 44.1 kHz, JEITA)
  20 Hz – 22 kHz, +0/−1 dB
  (MIC/EXT IN to LINE OUT, 48 kHz, JEITA)
  20 Hz – 40 kHz, +0/−1.5 dB
  (MIC/EXT IN to LINE OUT, 96 kHz, JEITA)
Total harmonic distortion ratio (THD+N) ≤0.01 %
  (MIC/EXT IN to LINE OUT, 44.1/48/96 kHz, JEITA)
Note: JEITA indicates conformance to JEITA CP-2150
Power supply and other specifications
Power supply 2 AA batteries (alkaline or NiMH, sold separately)
  USB bus power from a computer
  Dedicated AC adapter (TASCAM PS-P520U, sold separately, DC 5 V, 2 A)
Power consumption 1.7 W / 5 V, 0.5 A (maximum)
Dimensions (W × H × D) 68 mm × 160 mm × 27 mm (microphones in XY configuration)
  90 mm × 160 mm × 27 mm (microphones pair in AB configuration)
Weight 184/136 g (with/without batteries)
Permissible operating temperature range 0–40 °C
